There are a few different ways of doing this but basically you have to make the heatsinks NOT live and you have to provide better cooling for the transistors. The heatsinks used in PSUs are generally soldered to the PCB via little metal tabs and current usually flows through them, ie they are live with voltage and act as part of the circuit. What you have to do is cut the tabs which takes the heatsinks out of the circuit and them use wire to replace them in part of the circuit.

This is a very simple design of digital oscilloscope. The original project comes from EP 8/2004. The only difference I've made was adding RS232 to USB converter to use it with my laptop. Schematic can by found here: analogue and digital. There can be seen analogue input section with OPA2350 amplifiers and relays as voltage dividers. ADC is fast television IC, TDA8703. Digital data goes through DS89C420, via USB to PC application showing results. It is harder and harder to find RS232 connector in modern computers. That's why I decided to make this converter. I doubt there is at least one computer without USB.

If you need to add simple data acquisition capabilities to your PC, then look no further than the Analog Interface Unit. The Analog Interface Unit (AIU) is a simple circuit that connects to a PC parallel port, and allows you to sample and output 8-bit analog signals under software control. Here are some of the features : * 8-bit ADC and DAC * Powered from the parallel port * 1Mohm input impedance. * Software selectable +/-1.25V or +/-2.5V input and output ranges.

Simple PC Steering Wheel. Jest to schemat prostej kierownicy do PC. Nie jest to najnowszy model kierownicy z pełnym wyposażeniem i dodatkami typu obsługa wstrząsów, ale proste i tanie urządzenie nie wymagające dużej wiedzy do jej budowy. Naszą kierownicę należy obudować najlepiej w jakąś wytrzymałą i estetyczną obudowę. Potencjometry BRAKE i GAS należy obudować w jakieś pedały (popatrz jak wygląda pedał do regulacji prędkości przy maszynie do szycia). Po poprawnym i dokładnym zmontowaniu kierownica powinna działać bez zarzutów.

This small realization, based on one of the most common IC (MAX232) is designed to create a small and convenient TTL to RS232 and vice versa converter. All you need is 4 caps, one IC and 2 connectors. If you want to add a small regulator on the board (already foreseen on the PCB) you just need to add a 78L05 regulator and a cap.

The UBW board is a small board that contains a Microchip PIC USB-capable microcontroller, headers to bring out all of the PICs signal lines (to a breadboard for example), only costs about $15-$20 to build and is powered from the USB connection. I designed this board to be a simple parallel port replacement tool for Bruce Shapiro for use in his bits-to-bytes-to-bots class. Apologies to all other 'Whacker' projects like EDTP's Packet Whacker for stealing a great name . All tools used to design this project are free, and the design is open to anyone to use for whatever they wish. Please build your own and improve upon it!

The circuit's pretty simple, basicly it's just a voltage regulator. Both the LM317 and the REG1117A (LDO) fit the PCB, maybe there are even more types that I'm aware of that can be used on it. I did add one extra thing: a LED that shows if the connected device is consuming power. To do this I used a shunt resistor and a current converter. I choose 0.2 ohm for the shunt, since it's not hard to come by and should only drop 0.1V @ 500mA. Either an INA168 (current output) or an INA193-198 (INA194 is best in this case) (voltage output) will fit as current converter. The trip point at which the LED should start to burn can easily be adjusted by one resistor (in case of the INA168) or by two (in case of the INA193-198). In the schematic it is set at 100mA using an INA168 using a 950k resistor. The Schmit buffer is a Texas Instruments Little Logic chip (1G17).

USB switch is used to share USB devices such as printers, scanners, hard drivers, etc. between two computers. Just connect the two computers on a network device and say the printer as shared. This method however requires the continued operation of the computer we plugged the printer. Solution to above problem is to give the circuit that we present, and has the potential to be transferred to the printer on whichever computer we want, because the printer is connected to one of two computers, but in construction.

USB to Serial Adapter RS-232 Serial Port to USB The USB to Serial adapter (converter) lets you use a serial PDA, GPS, cell, etc. with a standard USB port. This adapter is the easiest way to add a serial port to your computer. Many PDAs, digital cameras, GPS units, barcode scanners, and other equipment require a serial connection, and many newer computers don't have serial ports.

USB to serial interface is based on the powerful FT232 chip from FTDI. It enables very easy connection of the user's application to the PC via the USB port, without necessity of any deep knowledge about the complicated USB problems. FT232 chip is capable to transfer data at speeds up to 1M Baud in RS232 mode and up to 3M Baud in the RS485 mode. Schematic contains the on-board serial EEPROM (93LC46) for storing the ID data (VID, PID, serial number and description strings).
