0.1uF / 50V Capacitor
0.1uF / 50V ceramic capacitor with standard 0.1' lead spacing. Excellent for decoupling integrated circuits. Fits into breads and perfboards. |
|
|
|
4.7uF / 35V ELNA SILMIC II Audio Capacitor
The SILMIC II series are Elna's highest grade audio aluminum electrolytic capacitors that exhibit superior acoustic characteristics. An entirely new type of electrolytic separating paper is used, containing silk fibers. The extreme softness of silk can mitigate vibrational energy (generated by the electrodes, by external vibrations and by electromagnetic fields). Due to it's new electrolytic and foil design the signal propagation speed has increased (the ESR is reduced) and a more powerful, yet-mellow, sound is possible than before. When these capacitors were subjected to aural evaluations, the high range peak and midrange roughness were reduced substantially. Also, the low range richness and power were increased in the obtained high-quality sound.
Features
 SIMIC II Highest Grade Audio capacitor
Uses Silk Fibers
Low ESR
Oxygen-free Copper Lead Wires (provide extremely low distortion)
Excellent for Power Amplifier / SACD / CD Player Upgrades
Fidelity is similar to Black Gate capacitors yet at much lower cost
Specifications
Dimensions: 5 mm x 11 mm (W x L)
Lead Spacing: 2 mm
Vinyl sleeve is of brown finish with SILMIC II mark |
|
|
|
10uF / 50V Rubycon Black Gate Capacitor - High-End Audio Capacitor
Black Gate is the name of a brand of audio grade electrolytic capacitor made in Japan. They have acquired a reputation for very high quality for use in the signal path, and power supplies, of audio circuitry. While debatable, the Black Gate capacitors are said by some to be the most significant upgrade that can be made to Hi-Fi equipment. They continue to be held in high regard by many high-end Hi-Fi manufacturers; tending to be used only in their most expensive, or signature, lines due to their high cost. |
|
|
|
10uF / 100V Nichicon MUSE Audio Series
Nichicon Muse KZ is Nichicon's top of the line audio electrolytic capacitor.
Features
Premium grade Nichicon MUSE KZ acoustic series.
Ideally suited for first class audio equipment where qualitative and quantitative comfortableness is required.
Specifications
Nichicon Capacitor Series: MUSE KZ (highest grade Nichicon Muse capacitors)
Capacitor Type: Aluminum Electrolytic Capacitor
Voltage: 100V
Dimensions: 8 x 11.5 mm (Diameter x Length) |
|
|
|
22uF / 25V ELNA SILMIC II Audio Capacitor
The SILMIC II series are Elna's highest grade audio aluminum electrolytic capacitors that exhibit superior acoustic characteristics. An entirely new type of electrolytic separating paper is used, containing silk fibers. The extreme softness of silk can mitigate vibrational energy (generated by the electrodes, by external vibrations and by electromagnetic fields). Due to it's new electrolytic and foil design the signal propagation speed has increased (the ESR is reduced) and a more powerful, yet-mellow, sound is possible than before. When these capacitors were subjected to aural evaluations, the high range peak and midrange roughness were reduced substantially. Also, the low range richness and power were increased in the obtained high-quality sound.
Features
SIMIC II Highest Grade Audio capacitor
Uses Silk Fibers
Low ESR
Oxygen-free Copper Lead Wires (provide extremely low distortion)
Excellent for Power Amplifier / SACD / CD Player Upgrades
Fidelity is similar to Black Gate capacitors yet at much lower cost
Specifications
Dimensions: 5 mm x 11 mm (W x L)
Lead Spacing: 2 mm
Vinyl sleeve is of brown finish with SILMIC II mark |
|
|
|
22uF 50V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 5 mm
Length: 11 mm
Lead Spacing: 2 mm
ESR: 0.22 Ohm
Life: 2000 hours
Temperature Rating: 105C
Ripple Current: 250 mA |
|
|
|
33uF / 25V Nichicon MUSE Audio Series
Nichicon Muse KZ is Nichicon's top of the line audio electrolytic capacitor.
Features
Premium grade Nichicon MUSE KZ acoustic series.
Ideally suited for first class audio equipment where qualitative and quantitative comfortableness is required.
Specifications
Nichicon Capacitor Series: MUSE KZ (highest grade Nichicon Muse capacitors)
Capacitor Type: Aluminum Electrolytic Capacitor
Voltage: 25V
Dimensions: 8 x 11.5 mm (Diameter x Length) |
|
|
|
47uF / 10V ELNA SILMIC II Audio Capacitor
The SILMIC II series are Elna's highest grade audio aluminum electrolytic capacitors that exhibit superior acoustic characteristics. An entirely new type of electrolytic separating paper is used, containing silk fibers. The extreme softness of silk can mitigate vibrational energy (generated by the electrodes, by external vibrations and by electromagnetic fields). Due to it's new electrolytic and foil design the signal propagation speed has increased (the ESR is reduced) and a more powerful, yet-mellow, sound is possible than before. When these capacitors were subjected to aural evaluations, the high range peak and midrange roughness were reduced substantially. Also, the low range richness and power were increased in the obtained high-quality sound.
Features
SIMIC II Highest Grade Audio capacitor
Uses Silk Fibers
Low ESR
Oxygen-free Copper Lead Wires (provide extremely low distortion)
Excellent for Power Amplifier / SACD / CD Player Upgrades
Fidelity is similar to Black Gate capacitors yet at much lower cost
Specifications
Dimensions: 5 mm x 11 mm (W x L)
Lead Spacing: 2.5 mm
Vinyl sleeve is of brown finish with SILMIC II mark |
|
|
|
47uF 25V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 5 mm
Length: 11 mm
Lead Spacing: 2 mm
ESR: 0.22 Ohm
Life: 2000 hours
Temperature Rating: 105C
Ripple Current: 280 mA |
|
|
|
100uF / 25V ELNA SILMIC II Audio Capacitor
The SILMIC II series are Elna's highest grade audio aluminum electrolytic capacitors that exhibit superior acoustic characteristics. An entirely new type of electrolytic separating paper is used, containing silk fibers. The extreme softness of silk can mitigate vibrational energy (generated by the electrodes, by external vibrations and by electromagnetic fields). Due to it's new electrolytic and foil design the signal propagation speed has increased (the ESR is reduced) and a more powerful, yet-mellow, sound is possible than before. When these capacitors were subjected to aural evaluations, the high range peak and midrange roughness were reduced substantially. Also, the low range richness and power were increased in the obtained high-quality sound.
Features
SIMIC II Highest Grade Audio capacitor
Uses Silk Fibers
Low ESR
Oxygen-free Copper Lead Wires (provide extremely low distortion)
Excellent for Power Amplifier / SACD / CD Player Upgrades
Fidelity is similar to Black Gate capacitors yet at much lower cost
Specifications
Dimensions: 10 mm x 16 mm (W x L)
Lead Spacing: 5 mm
Vinyl sleeve is of brown finish with SILMIC II mark |
|
|
|
100uF / 25V Nichicon MUSE Audio Series
Nichicon Muse KZ is Nichicon's top of the line audio electrolytic capacitor.
Features
Premium grade Nichicon MUSE KZ acoustic series.
Ideally suited for first class audio equipment where qualitative and quantitative comfortableness is required.
Specifications
Nichicon Capacitor Series: MUSE KZ (highest grade Nichicon Muse capacitors)
Capacitor Type: Aluminum Electrolytic Capacitor
Voltage: 25V
Dimensions: 10 x 16 mm (Diameter x Length) |
|
|
|
100uF 25V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 6 mm
Length: 11 mm
Lead Spacing: 5 mm
ESR: 0.1 Ohm
Life: 2000 hours
Temperature Rating: 105C
Ripple Current: 455 mA |
|
|
|
100uF 50V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 8 mm
Length: 11.5 mm
Lead Spacing: 3.5 mm
ESR: 0.06 Ohm
Life: 3000 hours
Temperature Rating: 105C
Ripple Current: 870 mA |
|
|
|
220uF / 25V Nichicon MUSE Audio Series
Nichicon Muse KZ is Nichicon's top of the line audio electrolytic capacitor.
Features
Premium grade Nichicon MUSE KZ acoustic series.
Ideally suited for first class audio equipment where qualitative and quantitative comfortableness is required.
Specifications
Nichicon Capacitor Series: MUSE KZ (highest grade Nichicon Muse capacitors)
Capacitor Type: Aluminum Electrolytic Capacitor
Voltage: 25V
Dimensions: 12.5 x 20 mm (Diameter x Length) |
|
|
|
220uF 25V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 8 mm
Length: 11.5 mm
Lead Spacing: 3.5 mm
ESR: 0.05 Ohm
Life: 3000 hours
Temperature Rating: 105C
Ripple Current: 950 mA |
|
|
|
470uF 10V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 8 mm
Length: 11 mm
Lead Spacing: 3.5 mm
ESR: 0.04 Ohm
Life: 3000 hours
Temperature Rating: 105C
Ripple Current: 950 mA |
|
|
|
470uF / 25V Nichicon MUSE Audio Series
Nichicon Muse KZ is Nichicon's top of the line audio electrolytic capacitor.
Features
Premium grade Nichicon MUSE KZ acoustic series.
Ideally suited for first class audio equipment where qualitative and quantitative comfortableness is required.
Specifications
Nichicon Capacitor Series: MUSE KZ (highest grade Nichicon Muse capacitors)
Capacitor Type: Aluminum Electrolytic Capacitor
Voltage: 25V
Dimensions: 16 x 25 mm (Diameter x Length) |
|
|
|
470uF 16V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 8 mm
Length: 15 mm
Lead Spacing: 5 mm
ESR: 0.04 Ohm
Life: 3000 hours
Temperature Rating: 105C
Ripple Current: 1.24A |
|
|
|
470uF / 50V Nichicon MUSE Audio Series
Nichicon Muse KZ is Nichicon's top of the line audio electrolytic capacitor.
Features
Premium grade Nichicon MUSE KZ acoustic series.
Ideally suited for first class audio equipment where qualitative and quantitative comfortableness is required.
Specifications
Nichicon Capacitor Series: MUSE KZ (highest grade Nichicon Muse capacitors)
Capacitor Type: Aluminum Electrolytic Capacitor
Voltage: 50V
Dimensions: 16 x 35.5 mm (Diameter x Length) |
|
|
|
1000uF / 25V Nichicon Muse KZ Series
Nichicon Muse KZ is Nichicon's top of the line audio electrolytic capacitor.
Features
Premium grade Nichicon MUSE KZ acoustic series.
Ideally suited for first class audio equipment where qualitative and quantitative comfortableness is required.
Specifications
Nichicon Capacitor Series: MUSE KZ (highest grade Nichicon Muse capacitors)
Capacitor Type: Aluminum Electrolytic Capacitor
Voltage: 25V
Dimensions: 16 x 35.5 mm (Diameter x Length) |
|
|
|
1000uF 6.3V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 10 mm
Length: 12.5 mm
Lead Spacing: 5 mm
ESR: 0.03 Ohm
Life: 4000 hours
Temperature Rating: 105C
Ripple Current: 1.29A |
|
|
|
1000uF 10V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 8 mm
Length: 20 mm
Lead Spacing: 3.5 mm
ESR: 0.03 Ohm
Life: 4000 hours
Temperature Rating: 105C
Ripple Current: 1.56A |
|
|
|
1000uF 16V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 10 mm
Length: 20 mm
Lead Spacing: 5 mm
ESR: 0.02 Ohm
Life: 5000 hours
Temperature Rating: 105C
Ripple Current: 2.18A |
|
|
|
2200uF 6.3V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 10 mm
Length: 25 mm
Lead Spacing: 5 mm
ESR: 0.01 Ohm
Life: 5000 hours
Temperature Rating: 105C
Ripple Current: 2.47A |
|
|
|
2200uF 10V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 12 mm
Length: 20 mm
Lead Spacing: 5 mm
ESR: 0.01 Ohm
Life: 5000 hours
Temperature Rating: 105C
Ripple Current: 2.6A |
|
|
|
2200uF 16V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 12 mm
Length: 25 mm
Lead Spacing: 5 mm
ESR: 0.02 Ohm
Life: 7000 hours
Temperature Rating: 105C
Ripple Current: 3.19A |
|
|
|
2200uF 16V United Chemi-Con Capacitor
High quality Japanese United Chemi-Con capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating. They are commonly used in high quality power supply units.
Diameter: 10 mm
Length: 30 mm
Lead Spacing: 5 mm
ESR: 0.01 Ohm
Life: 10000 hours
Temperature Rating: 105C
Ripple Current: 2.23A |
|
|
|
3300uF 16V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 12 mm
Length: 35 mm
Lead Spacing: 5 mm
ESR: 0.01 Ohm
Life: 7000 hours
Temperature Rating: 105C
Ripple Current: 3.75A |
|
|
|
4700uF 6.3V Panasonic FM Capacitor
High quality Japanese Panasonic FM capacitors feature ultra low ESR, low impedance, long lifetime and 105C temperature rating.
Diameter: 12 mm
Length: 30 mm
Lead Spacing: 5 mm
ESR: 0.01 Ohm
Life: 7000 hours
Temperature Rating: 105C
Ripple Current: 3.63A |
|
|
|
|
