Special Edition Accurate LC Meter Kit with Blue Backlight LCD - FREE CASE
Build your own Special Edition Accurate LC Meter (Inductance Meter / Capacitance Meter) and start making custom made precision coils and inductors. Accurate LC Meter allows to measure incredibly small inductances making it perfect tool for making all types of RF coils and inductors. It can measure inductance starting from only 10nH - 1000nH, 1uH - 1000uH, 1mH up to 100mH and capacitance from 0.1pF up to 900nF.
Special Edition LC Meter includes top notch high precision components that are only found in premium quality kits. It includes high quality double-sided printed circuit board (PCB) with red solder mask and pre-soldered tracks for easier soldering, detachable LCD display with blue LED backlight, programmed PIC16F628A microcontroller chip, high precision capacitors and inductor, 1% Metal Film resistors, Machined IC Sockets, gold plated header pins, LCD header connectors and all the other components that are needed to build a premium quality kit. Thanks to the use of LCD connectors LCD display can be detached from the main PCB board at any time even after the kit has been assembled. All components are through-hole and are easy to solder. Special Edition Accurate LC Meter is designed for professionals that require unprecedented measurement accuracy and offers great value at low cost.
View LC Meter Schematic and Detailed Description
Specifications:
 Measures following inductance: 10nH - 1000nH, 0.1uH - 1000uH, 0.1mH - 100mH
Measures following capacitance: 0.1pF - 1000pF, 0.1nF - 900nF
Voltage Supply: 6 - 16V
Current Consumption: 10mA
Dimensions: 80 mm x 36 mm x 23 mm (W x L x H)
Component List:
1x 16 x 2 LCD Display with Blue Backlight
1x Free Generic Case
1x LC Meter PCB
1x PIC16F628A Programmed Microcontroller IC
1x LM311 IC
1x Gold Plated Machined 18 DIP IC Socket
1x Gold Plated Machined 8 DIP IC Socket
1x LM7805 5V Regulator
1x 10K Potentiometer
1x High Grade 82uH Inductor
1x 4.000 MHz Crystal
1x 5V Reed Relay
1x L/C Pushbutton Switch with Black Cap
1x Tactile momentary reset switch with Black Cap
3x Panasonic 10uF Capacitor
1x High Grade 100nF Capacitor
2x High Precision 1000pF Capacitor
2x High Grade 10pF Capacitor
1x Gold Plated 16-PIN LCD Female Header
1x Gold Plated 16-PIN LCD Male Header
1x Gold Plated 2-PIN Header
2x Gold Plated 1-PIN Header
3x 1% Metal Film 100K Resistor
1x 1% Metal Film 47K Resistor
2x 1% Metal Film 6.8K Resistor
1x 1% Metal Film 1K Resistor
1x 1% Metal Film 100 Resistor
1x 1% Metal Film 10 Resistor |
|
|
|
Special Edition Accurate LC Meter Kit with Green Backlight LCD - FREE CASE
Build your own Special Edition Accurate LC Meter (Inductance Meter / Capacitance Meter) and start making custom made precision coils and inductors. Accurate LC Meter allows to measure incredibly small inductances making it perfect tool for making all types of RF coils and inductors. It can measure inductance starting from only 10nH - 1000nH, 1uH - 1000uH, 1mH up to 100mH and capacitance from 0.1pF up to 900nF.
Special Edition LC Meter includes top notch high precision components that are only found in premium quality kits. It includes high quality double-sided printed circuit board (PCB) with red solder mask and pre-soldered tracks for easier soldering, detachable LCD display with yellow-green LED backlight, programmed PIC16F628A microcontroller chip, high precision capacitors and inductor, 1% Metal Film resistors, Machined IC Sockets, gold plated header pins, LCD header connectors and all the other components that are needed to build a premium quality kit. Thanks to the use of LCD connectors LCD display can be detached from the main PCB board at any time even after the kit has been assembled. All components are through-hole and are easy to solder. Special Edition Accurate LC Meter is designed for professionals that require unprecedented measurement accuracy and offers great value at low cost.
View LC Meter Schematic and Detailed Description
Specifications:
Measures following inductance: 10nH - 1000nH, 0.1uH - 1000uH, 0.1mH - 100mH
Measures following capacitance: 0.1pF - 1000pF, 0.1nF - 900nF
Voltage Supply: 6 - 16V
Current Consumption: 10mA
Dimensions: 80 mm x 36 mm x 23 mm (W x L x H)
Component List:
1x 16 x 2 LCD Display with Yellow-Green Backlight
1x Free Generic Case
1x LC Meter PCB
1x PIC16F628A Programmed Microcontroller IC
1x LM311 IC
1x Gold Plated Machined 18 DIP IC Socket
1x Gold Plated Machined 8 DIP IC Socket
1x LM7805 5V Regulator
1x 10K Potentiometer
1x High Grade 82uH Inductor
1x 4.000 MHz Crystal
1x 5V Reed Relay
1x L/C Pushbutton Switch with Black Cap
1x Tactile momentary reset switch with Black Cap
3x Panasonic 10uF Capacitor
1x High Grade 100nF Capacitor
2x High Precision 1000pF Capacitor
2x High Grade 10pF Capacitor
1x Gold Plated 16-PIN LCD Female Header
1x Gold Plated 16-PIN LCD Male Header
1x Gold Plated 2-PIN Header
2x Gold Plated 1-PIN Header
3x 1% Metal Film 100K Resistor
1x 1% Metal Film 47K Resistor
2x 1% Metal Film 6.8K Resistor
1x 1% Metal Film 1K Resistor
1x 1% Metal Film 100 Resistor
1x 1% Metal Film 10 Resistor |
|
|
|
BA1404 HI-FI Stereo FM Transmitter - Special Edition Kit
Be "On Air" with your own radio station! BA1404 HI-FI Stereo FM Transmitter - Special Edition Kit is an exciting transmitter that will broadcast high quality stereo signal in 88MHz - 108MHz FM band. It can be connected to any type of stereo audio source such as iPod, Computer, Laptop, CD Player, Walkman, Television, Satellite Receiver, Tape Deck or other stereo system to transmit stereo sound with excellent clarity throughout your home, office, yard or camp ground. Add 500mW FM / VHF Transmitter Amplifier / Booster for even longer range.
Special Edition BA1404 HI-FI Stereo FM Transmitter Kit includes premium components with audio grade gold capacitors, 1% Metal Film Resistors and quality PCB with Red Solder Mask and Plated-Through Holes. The kit is based on the popular BA1404 stereo broadcaster IC which contains all the complex circuitry for generating the stereo FM signal. 38 KHz crystal provides a rock solid stability of sub-carrier for stereo signal.
Specifications:
Voltage Supply: 1.5 - 3V DC Input (Single or Two AA/AAA batteries)
Frequency: 88MHz - 108MHz
Audio Input: Stereo
PCB Dimensions: 49mm x 32mm (W x H)
Kit Components
1x BA1404 Stereo FM Transmitter IC
1x PCB with Red Solder Mask and Plated-Through Holes
1x 38KHz Crystal Oscillator
1x 3.5T Variable Precision RF Coil
1x 10uH Inductor
4x 10uF/50V Gold Audio Capacitors
4x 1nF Ceramic Capacitors
2x 1nF Mylar Capacitors
1x 220pF Ceramic Capacitor
5x 10pF Ceramic Capacitors
2x 47K 1% Metal Film Resistors
2x 27K 1% Metal Film Resistors
1x 150K 1% Metal Film Resistor
1x 5.6K 1% Metal Film Resistor
1x 270 1% Metal Film Resistor
1x Instructions |
| Quantity Discounts |
| 1: |
$25.95 |
| 10: |
$24.95 |
| 25: |
$22.95 |
|
|
|
60MHz Frequency Meter / Counter Kit - Blue Backlight LCD
This is 60MHz Frequency Meter / Counter for measuring frequency from 10Hz to 60MHz with 10Hz resolution. It is a very useful bench test equipment for testing and finding out the frequency of various devices with unknown frequency such as oscillators, radio receivers, transmitters, function generators, crystals, etc. The meter provides very stable readings and has excellent input sensitivity thanks to onboard amplifier and TTL converter, so it can even measure weak signals from crystal oscillators. With the addition of prescaller it is possible to measure the frequency of 1GHz and above. The meter measuring range has been extended and it can now measure up to 60MHz instead of 50MHz.
Click here for more information and schematic
Specifications
Voltage Supply: 7V - 16V
Power Consumption: 80mA with LCD backlight
Frequency Measurement: 10Hz - 60MHz
Measurement Resolution: 10Hz
Component List
1x 16 x 2 LCD Display with Blue Backlight
1x PIC16F628A Programmed Microcontroller
1x PCB
1x 28-DIP IC Socket
1x 4.000MHz Crystal
1x LM7805 5V Voltage Regulator
1x 1 x 16 Gold Plated Female Header (for PCB)
1x 1 x 16 Gold Plated Male Header (for LCD)
2x 1 x 2 Gold Plated Male Header (for LCD)
1x BF199
1x 10uH Inductor
1x 10K Trimmer
1x 10K 1% Metal Film Resistor
2x 470 1% Metal Film Resistor
1x 10 1% Metal Film Resistor
2x 100nF Ceramic Capacitor
2x 33pF Ceramic Capacitor
1x Manual with Schematic
Related Products
1Hz - 2MHz XR2206 Function Generator Kit
|
|
|
|
1Hz - 2MHz XR2206 Function Generator Kit
Premium quality XR2206 Function Generator kit capable of producing high quality sine, square and triangle waveforms of high-stability and accuracy. The output waveforms can be both amplitude and frequency modulated. Coarse frequency adjustment is accomplished using 4-DIP switch for the following four frequency ranges; (1) 1Hz-100Hz, (2) 100Hz-20KHz, (3) 20KHz-1MHz, (4) 150KHz-2MHz. Frequency output can be fine tuned using P1 and P2 potentiometers. The kit includes output that can be connected to 60MHz Counter kit for displaying output frequency on LCD display. 1Hz - 2MHz XR2206 Function Generator kit includes premium quality components, including Audio Grade Gold Capacitors, Gold Plated RCA Connector, WIMA Capacitors, 1% Metal Film Resistors, two external switches and premium quality double-sided PCB with red solder mask and plated through holes.
XR2206 Function Generator Schematic
Sine Wave:
Amplitude: 0 - 3V at 9V DC input
Distortion: Less than 1% (at 1kHz)
Flatness: +0.05dB 1Hz - 100kHz
Square Wave:
Amplitude: 8V (no load) at 9V DC input
Rise Time: Less than 50ns (at 1kHz)
Fall Time: Less than 30ns (at 1kHz)
Symmetry: Less than 5% (at 1kHz)
Triangle Wave:
Amplitude: 0 - 3V at 9V DC input
Linearity: Less than 1% (up to 100kHz)
Specifications:
Voltage Supply: 9-18V DC Input
Waveforms: Square, Sine & Triangle
Impedance: 600Ω + 10%
Frequency: 1Hz - 2MHz in 4 steps ranges with fine adjustment
PCB Dimensions: 38mm x 69mm / 1.5" x 2.7"
Component List:
1x XR2206
1x Premium Quality PCB with Red Solder Mask
1x Gold Plated RCA Connector
1x Gold Plated 4-DIP Switch
1x Sine / Square Switch
1x Sine / Triangle Switch
2x 100K Potentiometer
1x 10K Potentiometer
1x 100uF / 50V Nichicon Gold Audio Grade Capacitor
2x 10uF / 35V Nichicon Gold Audio Grade Capacitor
1x 100nF WIMA Capacitor
1x 1nF WIMA Capacitor
1x 150pF Capacitor
3x 6.8K 1% Metal Film Resistor
2x 1K 1% Metal Film Resistor
1x 3-PIN Gold Plated Male Header
2x 2-PIN Gold Plated Male Header
1x Manual with Schematic
Related Products
60MHz Frequency Meter / Counter Kit |
|
|
|
USB IO Board Kit
USB IO Board is a tiny spectacular little Development Board, Data Acquisition and Parallel Port replacement featuring PIC18F2455/PIC18F2550 microcontroller. USB IO Board is compatible with Windows 2000, XP, VISTA, Win7, Mac OSX and Linux. When attached to Windows IO board will show up as RS232 COM port. You can control 16 individual microcontroller I/O pins by sending simple serial commands. USB Input / Output Board is self-powered by USB port and can provide up to 500mA for your project needs. USB IO Board is breadboard compatible. Simply solder included 12-PIN & 8-PIN male headers on the bottom side of the PCB and the board can be plugged into a breadboard for quick prototyping.
These are examples of what can be built using USB IO Board:
USB Relay Controller (turn ON/OFF lights or appliances in the house)
Control LEDs, toys, electronic gadgets, wireless control, etc.
USB LCD Controller
USB Volt / Ampere / Wattage / Pressure Meter
USB CNC Controller
USB Data Logger
USB Temperature Meter / Logger
USB Thermostat
USB Humidity Meter / Logger
USB Digital RF Power Meter
USB Stepper Motor Controller
USB RC Servo Controller
and much more
Specifications:
16 I/O PINs
USB 2.0 and USB 1.1 plug-and-play compatibility
USB Powered
Runs under Windows 2000, XP, VISTA, Win7, Mac OSX and Linux
5mA Current Consumption
PCB Dimensions: 18mm x 59mm / 0.7" x 2.3"
Click here for schematic, pictures and sample software
Component List:
1x PIC18F2455 / PIC18F2550 Programmed Microcontroller (MCU)
1x PCB
1x 28-DIP IC Socket
1x USB Type B Connector
1x Gold Plated 12-PIN LCD Male Header
1x Gold Plated 8-PIN LCD Male Header
1x 20MHz Crystal Resonator
2x 10K Resistor (brown black orange gold)
1x 10uF/35V Capacitor
1x 470nF Ceramic Capacitor
1x 100nF Ceramic Capacitor
1x Instructions with Schematic |
|
|
|
Voltmeter Ammeter Kit - Blue Backlight LCD
Voltmeter Ammeter can measure voltage 0-70V or 0-500V with 100mV resolution and current consumption 0-10A or more with 10mA resolution. The meter is a perfect addition to any power supply, battery chargers and other electronic projects where voltage and current must be monitored. The meter uses PIC16F876A microcontroller with built-in ADC (Analog to Digital Converter) and 16 x 2 LCD display with blue backlight. With slight modification it is possible to measure higher voltage and current.
View Schematic
To measure voltage that is higher than 70 Volts simply replace R3 6.8K resistor with included 1K resistor. This will allow to measure up to 500 Volts.
To measure current that is higher than 10A simply replace 0.47 Ohm 5W power resistor with higher wattage or lower resistance resistor. For example 0.1 Ohm 10W resistor will allow to measure up to 20 Amps.
This kit comes with all the parts required to build Voltmeter Ammeter including PCB with beautiful red solder mask and plated through holes. Voltmeter can also measure AC voltage if rectifier bridge is added to voltage input. This meter can both measure and be supplied by the same power source.
Specifications
Voltage Supply: 6 - 30V
Current Consumption: 10mA
Voltage Input: 0 - 70V / 0 - 500V @ 100mV Resolution
Current Input: 10mA - 10A @ 10mA Resolution
Component List
1x 16 x 2 LCD Display with Blue Backlight
1x PIC16F876A - Programmed microcontroller
1x High Quality PCB with red solder mask and plated through holes
1x 28-DIP IC Socket
1x 4MHz Resonator
1x 16 x 1 Gold Plated Male Header
1x 16 x 1 Gold Plated Female Header
1x 4 x 1 Gold Plated Header
1x LM7805 5V Voltage Regulator
1x 10K Trimmer Potentiometer
1x 4 x 10K Network Resistor
2x 100K 1% Metal Film Resistor
2x 6.8K 1% Metal Film Resistor
1x 1K 1% Metal Film Resistor
1x 10 1% Metal Film Resistor
1x 0.47 Ohm 5W Power Resistor
1x 100nF Ceramic Capacitor
1x Manual with Schematic |
|
|
|
4-Channel 433MHz Wireless RF Remote Control Kit (200m)
Having the ability to control various appliances inside or outside of your house wirelessly is a huge convenience, and can make your life much easier and fun. RF remote control provides long range of up to 200m / 650ft and can find many uses for controlling different devices, and it works even through the walls. You can control lights, fans, AC system, computer, printer, amplifier, robots, garage door, security systems, motor-driven curtains, motorized window blinds, door locks, sprinklers, motorized projection screens and anything else you can think of.
Four button RF remote is used to turn ON / OFF four different devices independently. Any of the four outputs can be configured to work independently in either toggle or momentary mode. Outputs are buffered by BC549 NPN transistors and can drive low voltage devices directly or be connected to 5V / 12V / 24V relays to control appliances that use 110V / 220V mains voltage or any voltage of your choice.
Multiple remote systems can be used independently to control more than four appliances in the same location by changing the address code on 433MHz receiver and remote. It is also possible to use several remotes to control the same appliance such as garage door.
Click here for remote control schematic and description
Specifications
Output Mode: Toggle / Momentary
Transmission Frequency: 433MHz
Kit Voltage Supply: 5 - 24V
Relay Types: 5V / 12V / 24V
Receiver Dimensions: 45mm x 30mm x 7mm
Remote Control Dimensions: 52 mm x 40 mm x 14 mm (when antenna is not extended)
Component List
1x 4-Channel RF Remote Control Transmitter with 12V alkaline battery cell
1x 4-Channel RF Receiver
1x Printed Circuit Board (PCB)
1x PIC16F628A Programmed Microcontroller
1x 78L05 Voltage Regulator
1x 10uF Capacitor
1x 100n Ceramic Capacitor
4x BC549 Transistors
4x 1K Resistors
4x 1N4148 Protection Diodes
5x 2-PIN Headers
1x Instructions Manual |
|
|
|
Voltmeter Ammeter Kit
Voltmeter Ammeter can measure voltage 0-70V or 0-500V with 100mV resolution and current consumption 0-10A or more with 10mA resolution. The meter is a perfect addition to any power supply, battery chargers and other electronic projects where voltage and current must be monitored. The meter uses PIC16F876A microcontroller with built-in ADC (Analog to Digital Converter) and 16 x 2 LCD display with green backlight. With slight modification it is possible to measure higher voltage and current.
View Schematic
To measure voltage that is higher than 70 Volts simply replace R3 6.8K resistor with included 1K resistor. This will allow to measure up to 500 Volts.
To measure current that is higher than 10A simply replace 0.47 Ohm 5W power resistor with higher wattage resistor. For example 20W 0.47 Ohm resistor will allow to measure up to 20 Amps.
This kit comes with all the parts required to build Voltmeter Ammeter including PCB with beautiful red solder mask and plated through holes. Voltmeter can also measure AC voltage if rectifier bridge is added to voltage input. This meter can both measure and be supplied by the same power source.
Specifications
Voltage Supply: 6 - 30V
Current Consumption: 10mA
Voltage Input: 0 - 70V / 0 - 500V @ 100mV Resolution
Current Input: 10mA - 10A @ 10mA Resolution
Component List
1x 16 x 2 LCD Display with Green Backlight
1x PIC16F876A - Programmed microcontroller
1x High Quality PCB with red solder mask and plated through holes
1x 28-DIP IC Socket
1x 4MHz Resonator
1x 16 x 1 Gold Plated Male Header
1x 16 x 1 Gold Plated Female Header
1x 4 x 1 Gold Plated Header
1x LM7805 5V Voltage Regulator
1x 10K Trimmer Potentiometer
1x 4 x 10K Network Resistor
2x 100K 1% Metal Film Resistor
2x 6.8K 1% Metal Film Resistor
1x 1K 1% Metal Film Resistor
1x 10 1% Metal Film Resistor
1x 0.47 Ohm 5W Power Resistor
1x 100nF Ceramic Capacitor
1x Manual with Schematic |
|
|
|
4-Channel 433MHz Wireless RF Remote Control Kit (100m)
Having the ability to control various appliances inside or outside of your house wirelessly is a huge convenience, and can make your life much easier and fun. RF remote control provides long range of up to 100m / 325ft and can find many uses for controlling different devices, and it works even through the walls. You can control lights, fans, AC system, computer, printer, amplifier, robots, garage door, security systems, motor-driven curtains, motorized window blinds, door locks, sprinklers, motorized projection screens and anything else you can think of.
Four button RF remote is used to turn ON / OFF four different devices independently. Any of the four outputs can be configured to work independently in either toggle or momentary mode. Outputs are buffered by BC549 NPN transistors and can drive low voltage devices directly or be connected to 5V / 12V / 24V relays to control appliances that use 110V / 220V mains voltage or any voltage of your choice.
Multiple remote systems can be used independently to control more than four appliances in the same location by changing the address code on 433MHz receiver and remote. It is also possible to use several remotes to control the same appliance such as garage door.
Click here for remote control schematic and description
Specifications
Output Mode: Toggle / Momentary
Transmission Frequency: 433MHz
Kit Voltage Supply: 5 - 24V
Relay Types: 5V / 12V / 24V
Receiver Dimensions: 45mm x 30mm x 7mm
Remote Control Dimensions: 52 mm x 40 mm x 14 mm (when antenna is not extended)
Component List
1x 4-Channel RF Remote Control Transmitter with 12V alkaline battery cell
1x 4-Channel RF Receiver
1x Printed Circuit Board (PCB)
1x PIC16F628A Programmed Microcontroller
1x 78L05 Voltage Regulator
1x 10uF Capacitor
1x 100n Ceramic Capacitor
4x BC549 Transistors
4x 1K Resistors
4x 1N4148 Protection Diodes
5x 2-PIN Headers
1x Instructions Manual |
|
|
|
4-Channel 433MHz Wireless RF Remote Control Kit (200m) - Momentary
Having the ability to control various appliances inside or outside of your house wirelessly is a huge convenience, and can make your life much easier and fun. RF remote control provides long range of up to 200m / 650ft and can find many uses for controlling different devices, and it works even through the walls. You can control lights, fans, AC system, computer, printer, amplifier, robots, garage door, security systems, motor-driven curtains, motorized window blinds, door locks, sprinklers, motorized projection screens and anything else you can think of.
Four button RF remote is used to turn ON / OFF four different devices independently. All four outputs work independently in momentary mode. Outputs are buffered by BC549 NPN transistors and can drive low voltage devices directly or be connected to 5V /12V / 24V relays to control appliances that use 110V / 220V mains voltage or any voltage of choice.
Multiple remote systems can be used independently to control more than four appliances in the same location by changing the address code on 433MHz receiver and remote.
Click here for remote control schematic and description
Specifications
Output Mode: Momentary
Transmission Frequency: 433MHz
Kit Voltage Supply: 5 - 24V
Relay Types: 5V / 12V / 24V
Receiver Dimensions: 45mm x 30mm x 7mm
Remote Control Dimensions: 52 mm x 40 mm x 14 mm (when antenna is not extended)
Component List
1x 4-Channel RF Remote Control Transmitter with 12V alkaline battery cell
1x 4-Channel RF Receiver
1x Printed Circuit Board (PCB)
1x PIC16F628A Programmed Microcontroller
1x 78L05 Voltage Regulator
1x 10uF Capacitor
1x 100n Ceramic Capacitor
4x BC549 Transistors
4x 1K Resistors
4x 1N4148 Protection Diodes
5x 2-PIN Headers
1x Instructions Manual |
|
|
|
60MHz Frequency Meter / Counter Kit - Green Backlight LCD
This is 60MHz Frequency Meter / Counter for measuring frequency from 10Hz to 60MHz with 10Hz resolution. It is a very useful bench test equipment for testing and finding out the frequency of various devices with unknown frequency such as oscillators, radio receivers, transmitters, function generators, crystals, etc. The meter provides very stable readings and has excellent input sensitivity thanks to onboard amplifier and TTL converter, so it can even measure weak signals from crystal oscillators. With the addition of prescaller it is possible to measure the frequency of 1GHz and above. The meter measuring range has been extended and it can now measure up to 60MHz instead of 50MHz.
Click here for more information and schematic
Specifications
Voltage Supply: 7V - 16V
Power Consumption: 80mA with LCD backlight
Frequency Measurement: 10Hz - 60MHz
Measurement Resolution: 10Hz
Component List
1x 16 x 2 LCD Display with Green Backlight
1x PIC16F628A Programmed Microcontroller
1x PCB
1x 28-DIP IC Socket
1x 4.000MHz Crystal
1x LM7805 5V Voltage Regulator
1x 1 x 16 Gold Plated Female Header (for PCB)
1x 1 x 16 Gold Plated Male Header (for LCD)
2x 1 x 2 Gold Plated Male Header (for LCD)
1x BF199
1x 10uH Inductor
1x 10K Trimmer
1x 10K 1% Metal Film Resistor
2x 470 1% Metal Film Resistor
1x 10 1% Metal Film Resistor
2x 100nF Ceramic Capacitor
2x 33pF Ceramic Capacitor
1x Manual with Schematic
Related Products
1Hz - 2MHz XR2206 Function Generator Kit
|
|
|
|
500mW FM / VHF Transmitter Amplifier / Booster (Parts)
This is a high performance low noise 500mW amplifier / booster for all low power FM transmitters such as BA1404, BH1417, BH1415, 433MHz transmitter modules, etc. The amplifier chip is an integrated circuit containing multiple transistor stages and all other parts conveniently within a single small package. Boosting your FM transmitter has never been easier and the output signal can also directly drive 2n4427 or 2n3866 transistors for 1W or 5W of RF output power.
Specifications
Output Power: 500mW
Input Frequency: 50MHz - 1300MHz
Voltage Supply: 9-12V
Component List
1x High Performance FM / VHF Amplifier Chip
1x 10uH Choke
1x 220 Ohm
3x 1nF Ceramic Capacitor
1x Instructions and Schematic |
|
|
|
BA1404 HI-FI Stereo FM Transmitter Kit
Be "On Air" with your own radio station! BA1404 based transmitter is an exciting product that will broadcast high quality stereo signal in 88MHz - 108MHz FM band. It can be connected to any type of stereo audio source such as iPod, Computer, Laptop, CD Player, Walkman, Television, Satellite Receiver, Tape Deck or other stereo system to transmit stereo sound with excellent clarity throughout your home, office, yard or camp ground. Add 500mW FM / VHF Transmitter Amplifier / Booster for even longer range.
The circuit is based on the popular BA1404 stereo broadcaster IC which contains all the complex circuitry for generating the stereo FM signal. 38 KHz crystal provides a rock solid stability of sub-carrier for stereo signal. PCB includes green solder mask layer for easier soldering and protects wires that do not need soldering.
Kit Components
1x Printed Circuit Board [5 cm x 3.2 cm]
1x BA1404 Stereo FM Transmitter IC
1x 38KHz Crystal Oscillator
1x 3.5T Variable Precision RF Coil
1x 10uH Inductor
4x 10uF/35V Capacitor
4x 1nF Ceramic Capacitor
2x 1nF Mylar Capacitor
1x 220pF Ceramic Capacitor
5x 10pF Ceramic Capacitor
2x 47K Resistor
2x 27K Resistor
1x 150K Resistor
1x 5.6K Resistor
1x 270 Resistor
1x Instructions |
| Quantity Discounts |
| 1: |
$24.95 |
| 5: |
$23.95 |
| 10: |
$22.95 |
|
|
|
1000m 433MHz RF Transmitter Module
This tiny RF Transmitter module is great for building your own wireless remote control or wireless link. Remote control that allows to control different devices can be easily implemented with wide range of encoder/decoder chips (such as HOLTEK HT12E + HT12D or MC145026 + MC145027 available in our store) or PIC / AVR microcontrollers. RF Module can also be used for sending data at up to 9.6KB/s.
RF Transmitter Specifications:
TTL Compatible Input
Voltage Supply: 3 - 12V
Power Consumption: 5 - 45mA
Quiescent Current: 20uA
Max Transfer Rate: 9.6KB/s
Operating Frequency: 433MHz
Transmitting Range: 1000m
Dimensions: 19mm x 19mm x 8mm |
|
|
|
433MHz RF Receiver Module
This tiny RF Receiver module is great for building your own wireless remote control or wireless link. Remote control that allows to control different devices can be easily implemented with wide range of encoder/decoder chips (such as HOLTEK HT12E + HT12D or MC145026 + MC145027 available in our store) or PIC / AVR microcontrollers. RF Module can also be used for sending data at up to 4.8KB/s.
RF Receiver Specifications:
TTL Compatible Output
Voltage Supply: 5V
Power Consumption: 5mA
Receiving Sensitivity: -103 dB
Max Transfer Rate: 4.8KB/s
Operating Frequency: 433MHz
Dimensions: 30mm x 14mm x 7mm |
|
|
|
Wireless Stereo PLL FM Transmitter with LCD
Now you can use your MP3 Player to listen your favorite tunes through any FM stereo receiver. Wireless FM transmitter wirelessly connects portable music players to your car or home stereo quickly and easily. Just plug the FM Transmitter into the headphone jack of your MP3 or any audio source including iPOD, PDA, CD Player, Cassette player or connect it to your PC or laptop computer. Tune your card stereo or receiver to the clearest FM frequency, and enjoy your digital music with full sound and convenience. Add our 500mW FM / VHF Transmitter Amplifier / Booster for even longer range.
Features:
PLL tuned transmitter / exciter for rock solid frequency stability over the entire FM band
Displays Transmitted Frequency on blue backlighted LCD
100KHz frequency increments
Includes three frequency memory buttons
PCB includes antenna output to which a piece of wire, or standard VHF amplifier can be connected for greater transmission range
Uses PLL synthesizer chip up to 1.4GHz
Includes 3.5mm audio jack cable
Small size
Specifications:
Transmission range: 87.5 - 108.0MHz (100KHz intervals)
Current Consumption: 50mA
Power Source: Two AAA batteries
Frequency response: 20Hz - 20KHz
Separation: 50dB
Power Output: 50mW
Dimensions: 8cm x 5cm x 2.5cm (W x L x D) |
|
|
|
DS18S20 Dual Temperature Meter Kit - Blue Backlight LCD
This package includes all components including PCB that are needed to build DS18S20 Dual Temperature Meter Kit with 16 x 2 LCD display with blue backlight and two DS18S20 digital temperature sensors. Meter can display both Celsius and Fahrenheit values (together or individually) and is capable of measuring temperatures from -55 to 127 degrees Celsius (-67 to 260 degrees Fahrenheit). An excellent feature of this temperature meter is that it can measure temperatures remotely. DS18S20 sensors can be placed many meters away from the main circuit because they send the temperature readings as data, just over a two wire cable. DS18S20 sensors require no calibration at all, which means that all temperature readings are 100% accurate out of the box. PIC Dual Temperature Meter includes 6 display modes for arranging temperature information on LCD display to your own preference. Simply press and hold Display Mode tactile button for one second to switch to the next display mode. Display mode is automatically saved in non-volatile EEPROM memory so meter retains selected mode even after power is disconnected.
Specifications
Voltage Supply: 7.5V - 15V
Power Consumption: ~ 10mA with LCD backlight / ~ 3mA without LCD backlight
Display Modes: 6 - For arranging temperature information on LCD display to your own
preference. Modes can be set to append numbers "1:", "2:" & "Out:", "In:" labels so it is easier to identify connected DS1820 temperature sensors.
Component List
1x 16 x 2 LCD Display with Blue Backlight
1x Printed Circuit Board (PCB)
1x PIC16F628A Pre-programed microcontroller
2x DS18S20 1-Wire Digital Temperature Sensor
1x LM7805 5V Voltage Regulator
1x 1 x 16 Female Gold Plated Header (for PCB)
1x 1 x 16 Male Gold Plated Header (for LCD)
1x 4-PIN Male Gold Plated Header
1x 2-PIN Male Gold Plated Header
1x 10K Trimmer Potentiometer
1x 10K Resistor
2x 1K Resistor
1x 10 Ohm Resistor
1x Tactile switch
1x Instruction Manual |
|
|
|
4-Channel 433MHz Wireless RF Remote Control - 100m (Transmitter + Receiver)
4 Channel RF Remote Transmitter and Receiver allows to remotely control four appliances. RF Remote Control provides 4 momentary outputs that can be wired to relays and control home appliances, lights, motors, light dimmers, robotic devices, RC cars, computer, etc. RF transmitter provides up to 100m range. Selection of custom address codes (by soldering pins) allows to operate more than one remote control system in the same area or to control one receiver with multiple transmitters. If required momentary outputs can be converted to toggle with low cost digital 4013 IC. 12V (27A) alkaline battery is included.
Features:
4 Momentary Outputs
100m Transmission Range
Small Size
Rock-solid oscillator provides reliable operation
Valid transmission (VT) pin is energized if any button on the remote is pressed
High noise immunity
Terminal pins provide simple connection to power supply and four devices
Selection of custom address codes (by soldering pins) allows to operate more than one unit in the same area
RF Transmitter Specifications:
Voltage Supply: 12V (Included 27A Alkaline Battery)
Transmission Frequency: 433MHz
Transmission Range: 100m
Dimensions: 52 mm x 40 mm x 14 mm
RF Receiver Specifications:
Voltage Supply: 5V
Transmission Frequency: 433 MHz
Output Mode: Momentary
Power Consumption: 5 mA
Receiving Sensitivity: -101 dbm
Dimensions: 36 mm x 25 mm x 8 mm |
|
|
|
300m FM Transmitter
This is a very powerful 'bug' for its size, 3V supply and number of components. This circuit includes a sensitive monaural microphone and can transmit over 300 meters on an open range. Easily tunable in the FM band by a variable capacitor. The range can be extended by increasing input voltage up to 9V. Add 500mW FM / VHF Transmitter Amplifier / Booster for even longer range.
Specifications:
Dimensions: 1-3/4" (L) 3/4" (W) 1/2" (H)
Power: Requires 2 AA batteries, 9 volt battery can be used to increase range
FM Transmitter frequency is user selectable
Transmitter can be listened to on any FM radio |
|
|
|
DS18S20 Temperature Meter Kit - Blue Backlight LCD
DS18S20 Temperature Meter Kit with 16 x 2 LCD display with blue backlight and one DS18S20 digital temperature sensor. Meter can display both Celsius and Fahrenheit values (together or individually) and is capable of measuring temperatures from -55 to 127 degrees Celsius (-67 to 260 degrees Fahrenheit). An excellent feature of this temperature meter is that it can measure temperature remotely. DS18S20 sensor can be placed many meters away from the main circuit because it sends temperature reading as data, just over a two wire cable. DS18S20 sensor requires no calibration at all, which means that temperature reading is 100% accurate. DS18S20 Temperature Meter can be set to display temperature in either Celsius or Fahrenheit, or Celsius with Fahrenheit degrees. Second DS18S20 sensor (purchased separately) may be attached to display temperature in two different locations.
Specifications
Voltage Supply: 7.5V - 15V
Power Consumption: ~ 10mA with LCD backlight / ~ 3mA without LCD backlight
Display Modes: For arranging temperature information on LCD display to your own
preference. Mode 1: Celsius, Mode 2: Fahrenheit, Mode 3: Celsius + Fahrenheit
Component List
1x 16 x 2 LCD Display with Blue Backlight
1x Printed Circuit Board (PCB)
1x PIC16F628A Pre-programed microcontroller
1x DS18S20 1-Wire Digital Temperature Sensor
1x LM7805 5V Voltage Regulator
1x 1 x 16 Female Gold Plated Header (for PCB)
1x 1 x 16 Male Gold Plated Header (for LCD)
1x 4-PIN Male Gold Plated Header
1x 2-PIN Male Gold Plated Header
1x 10K Trimmer Potentiometer
1x 10K Resistor
2x 1K Resistor
1x 10 Ohm Resistor
1x Tactile switch
1x Instruction Manual |
|
|
|
BH1417 Stereo PLL FM Transmitter Parts
These are all components that are needed to build a BH1417 Stereo PLL FM Transmitter project. Add our 500mW FM / VHF Transmitter Amplifier / Booster for even longer range.
Component List
1x BH1417 - Stereo PLL Transmitter IC
1x 7.6 MHz Crystal
1x 2.5 Turns Variable Coil
1x MV2109 Varicap Diode
1x 4-DIP Switch
1x MPSA13 NPN Darlington Transistor
1x 100uF Capacitor
3x 10uF Capacitor
2x 1uF Capacitor
1x 47nF Capacitor
3x 2.2nF Capacitor
1x 1nF Capacitor
1x 330pF Capacitor
2x 150pF Capacitor
1x 33pF Capacitor
2x 27pF Capacitor
1x 22pF Capacitor
2x 10pF Capacitor
1x 22K Resistor
7x 10K Resistor
1x 5.1K Resistor
2x 3.3K Resistor
1x 100 Ohm Resistor |
|
|
|
DS18S20 Dual Temperature Meter Kit - Green Backlight LCD
This package includes all components including PCB that are needed to build DS18S20 Dual Temperature Meter Kit with 16 x 2 LCD display with green backlight and two DS18S20 digital temperature sensors. Meter can display both Celsius and Fahrenheit values (together or individually) and is capable of measuring temperatures from -55 to 127 degrees Celsius (-67 to 260 degrees Fahrenheit). An excellent feature of this temperature meter is that it can measure temperatures remotely. DS18S20 sensors can be placed many meters away from the main circuit because they send the temperature readings as data, just over a two wire cable. DS18S20 sensors require no calibration at all, which means that all temperature readings are 100% accurate out of the box. PIC Dual Temperature Meter includes 6 display modes for arranging temperature information on LCD display to your own preference. Simply press and hold Display Mode tactile button for one second to switch to the next display mode. Display mode is automatically saved in non-volatile EEPROM memory so meter retains selected mode even after power is disconnected.
Specifications
Voltage Supply: 7.5V - 15V
Power Consumption: ~ 10mA with LCD backlight / ~ 3mA without LCD backlight
Display Modes: 6 - For arranging temperature information on LCD display to your own
preference. Modes can be set to append numbers "1:", "2:" & "Out:", "In:" labels so it is easier to identify connected DS1820 temperature sensors.
Component List
1x 16 x 2 LCD Display with Green Backlight
1x Printed Circuit Board (PCB)
1x PIC16F628A Pre-programed microcontroller
2x DS18S20 1-Wire Digital Temperature Sensor
1x LM7805 5V Voltage Regulator
1x 1 x 16 Female Gold Plated Header (for PCB)
1x 1 x 16 Male Gold Plated Header (for LCD)
1x 4-PIN Male Gold Plated Header
1x 2-PIN Male Gold Plated Header
1x 10K Trimmer Potentiometer
1x 10K Resistor
2x 1K Resistor
1x 10 Ohm Resistor
1x Tactile switch
1x Instruction Manual |
|
|
|
50mW PLL FM Transmitter / SD USB MP3 Player
Excellent quality PLL FM Transmitter / MP3 Player that plays mp3 files stored on USB flash drive or SD memory card. Transmitter comes with input jack and cable connect to other audio sources such as MP3 players, satellite receivers, etc. USB and SD connector is attached to PCB. Included IR Remote control allows to quickly change frequency, songs, switch folders, adjust volume control, change equalizer settings and switch to songs using numeric pad. Transmitting frequency is conveniently displayed on backlighted LCD.
Features:
PLL tuned transmitter / exciter for rock solid frequency stability and clarity over the entire FM band
Displays Transmitted Frequency on backlighted LCD
PCB includes antenna output to which a piece of wire, or VHF amplifier can be connected for greater transmission range
Includes 3.5mm audio jack input cable for connecting to audio source such as MP3 Players
Plays MP3 songs from SD memory cards and USB flash drives with up to 256Kbps sampling rate. SD and USB connectors are attached to PCB board.
Comes with IR Remote
Connections:
Red wire 5-12V power input
Black wire GND power input
White wire antenna output
Specifications:
Transmission range: 87.5 - 108.0MHz
100KHz frequency steps
Current Consumption: 50mA
Power Source: 5V DC
Frequency response: 20Hz - 20KHz
Separation: 50dB
Power Output: 50mW
Dimensions: 3cm x 6cm x 1cm (W x L x D) |
|
|
|
5W PLL Stereo FM Transmitter (Assembled) - FREE SHIPPING
Features:
PLL synthesized drift free operation with high quality BH1415 chip
5W RF output power with 2SC1971 6W transistor in the output stage
Front panel digital control with LED display
Professional aluminum case
EMI filtering on audio and power inputs
Microphone and Audio inputs
Transmitter starts broadcasting with previously selected frequency
Professional broadcast audio quality, rivals commercial broadcasts
What's Included:
5W PLL Stereo FM Transmitter with Aluminum Case
12V / 2A Power Adapter 100V-240V
3.5mm Audio Cable
Technical Specifications:
Frequency: 87.0-109.0 MHz
Frequency steps: 100KHz
Stability: ±10ppm (-10° C+50°C)
Display: LED Display
FM Antenna impedance: 50Ω
Antenna connection: BNC/Q9
RF output power: 5W
Spurious and Harmonics: < -30dB
Modulation deviation: ≤±75kHz-100%
Modulation sensitivity: 0.75V
Audio input: CD, MP3, PC, etc.
Mic sensitivity: 1-2mv
Audio response: 20-15KHz
Audio distortion: ≤2% (F=75KHz,f=1KHz)
S/N: ≥55dB(1KHz 100%)
Power voltage: 8V-13.8V / 2A DC
Operation temperature: -10°C…+60°C
Weight: 390g
Unit dimensions: 105mm x 65mm x 27mm (LxWxH) |
|
|
|
RGB LED Candle (parts)
Simple RGB LED candle circuit with the use of PIC12F675 microcontroller and super bright RGB LED. RGB LED candle can be customized for either White, Red, Green, Blue, Violet and Yellow colors. Includes programmed ready to use PIC12F675 microcontroller. LED Candle can be supplied by either two or three AAA / AA batteries or 3V CR type button battery.
Specifications
Operating voltage: 2V - 5.5V
LED Colors: White, Red, Green, Blue, Violet and Yellow
Component List
1x Programmed PIC12F675 with LED Candle program (DIP-8 case)
1x Super Bright Clear RGB LED (5mm)
1x 100n Capacitor
1x Instructions with schematic |
|
|
|
USB Relay Controller
Control up to eight devices with your computer using this USB relay controller board. Use the free Relay Controller software to control your devices from a PC. 12V relays are not included.
Specifications:
Voltage Supply: 12V
PCB Dimensions: 18mm x 59mm / 0.7" x 2.3"
Component List:
1x PIC18F2455 / PIC18F2550 Programmed Microcontroller (MCU)
1x PCB
1x 28-DIP IC Socket
1x USB Type B Connector
1x Gold Plated 12-PIN LCD Male Header
1x Gold Plated 8-PIN LCD Male Header
1x 20MHz Crystal Resonator
8x BC549 Transistor
8x 1K Resistor
2x 10K Resistor
1x 470nF Ceramic Capacitor
1x 100nF Ceramic Capacitor
1x Instructions with Schematic
1x USB Relay Controller software (Win XP, VISTA, Win 7)
12V Relays are not included. |
|
|
|
USB Voltmeter Kit
USB Voltmeter is a PC based dual channel voltmeter built around PIC18F2455 / PIC18F2550 microcontroller that measures voltage from 0.00V up to 500.00V with 10mV resolution. USB Voltmeter sends measured data to PC via standard USB connection displaying data on a computer monitor. USB Voltmeter is self-powered drawing very little current from USB port. Voltage readings are displayed via included USB Voltmeter software.
Specifications:
Voltage Input Range: 0 - 500V
Voltage Input Channels: 2
Voltage Resolution: 10mV
Power Supply: 5V (USB Powered)
PCB Dimensions: 18mm x 59mm / 0.7" x 2.3"
Component List:
1x PIC18F2455 / PIC18F2550 Programmed Microcontroller (MCU)
1x USB Voltmeter PCB
1x 28-DIP IC Socket
1x USB Type B Connector
1x Gold Plated 12-PIN Male Header
1x Gold Plated 8-PIN Male Header
1x 20MHz Crystal Resonator
2x 100K 1% Metal Film Resistor
2x 10K Micro Resistor
2x 6.8K 1% Metal Film Resistor
2x 1K 1% Metal Film Resistor
1x 470nF Ceramic Capacitor
1x 100nF Ceramic Capacitor
1x Instructions with Schematic
1x USB Voltmeter software (Win XP, VISTA, Win 7) |
|
|
|
USB Thermometer Kit with Data Logger
USB Thermometer allows to measure temperature in two different locations. Two Microchip MCP9700 temperature sensors in standard TO-92 package are used to sample temperature and allow to measure temperature from -40 to +125 Celsius degrees. Simply connect to a PC computer via standard USB cable and temperature readings will be displayed using included USB Thermometer software. USB Thermometer takes power directly from USB port and does not need external power supply. Temperature readings can be displayed in both Fahrenheit and Celsius degrees.
USB Thermometer software comes with Data Logger feature. Date, time and temperature readings are saved to a text file and can be used to create various graphs via Microsoft Excel or any other statistical software. The software will log temperature every x amount of time which can be set from a second up to a day.
Specifications:
Temperature Range: -40 to +125 degrees Celsius
Voltage Supply: 5V (USB Powered)
PCB Dimensions: 18mm x 59mm / 0.7" x 2.3"
Component List:
1x PIC18F2455 / PIC18F2550 Programmed Microcontroller (MCU)
2x MCP9700 temperature sensors (TO-92 package)
1x PCB
1x 28-DIP IC Socket
1x USB Type B Connector
1x Gold Plated 12-PIN LCD Male Header
1x Gold Plated 8-PIN LCD Male Header
1x 20MHz Crystal Resonator
2x 10K Resistor
1x 470nF Ceramic Capacitor
1x 100nF Ceramic Capacitor
1x Instructions with Schematic
1x USB Thermometer software (Win XP, VISTA, Win 7) |
|
|
|
Accurate USB 0-500MHz RF Power Meter Kit
Measurement of transmitter output RF power has never been easier and more precise. Accurate USB 0-500MHz RF Power Meter allows to measure RF power of transmitters in dBm, Watts (nW, uW, mW and W range) as well as input voltage. USB RF Power Meter is based on popular AD8307 watt power meter IC and PIC18F2550 microcontroller. Instead of using LCD display module the meter connects to a PC via USB port and displays measurements on a computer via included USB RF Power Meter software. The software settings can be configured to use 10-50dBm attenuator and thus allowing to measure higher RF power than 2W.
Specifications:
Measures RF Power from 1nW to 2W / -66.6dBm to 30dBm
Auto-range RF Wattage Measurement: nW, uW, mW and W
Frequency Input: 0-500MHz
Self-powered by USB port
Can measure higher RF power with addition of simple 10-50dBm resistor attenuator
Component List:
1x USB RF Power Meter software (Windows 2000, XP, VISTA, Win7)
1x Windows 2000, XP, VISTA, Win7 Drivers
1x Programmed PIC18F2550 / PIC18F2455 Microcontroller
1x AD8307 8-DIP RF Power Meter IC
1x USB IO Board PCB
1x 28-DIP IC Socket
1x 8-DIP IC Socket
1x USB Type B Connector
1x 20MHz Crystal Resonator
1x 470n Capacitor
4x 100n Capacitor
2x 470K Resistor
2x 10K Resistor
2x 100 Ohm Resistor
1x Instructions with Schematic |
|
|
|
Micro SD MP3 Player
Complete MP3 Player that plays MP3 and WMA audio files stored on micro SD memory card. Comes with USB cable for charging built-in LIPO battery and transferring MP3/WMA files. 2GB/4GB/8GB Micro SD card must be purchased separately.
Features
Micro SD Card MP3 Player
Plays MP3 and WMA audio files stored on micro SD memory card
Button Functions: Play/Pause, Next / Skip 10 songs, Previous / Skip 10 songs, Volume Up and Volume Down
Support for 2GB, 4GB, 8GB Micro SD memory cards (not included)
Onboard connectors: Micro SD slot, 3.5mm headphone connector and micro USB connector
Support for USB 2.0 data transfer
Can be used as card reader
Includes built-in LIPO battery (rechargeable through USB connection)
Dimensions: 28mm x 40mm x 5mm |
|
|
|
NJM2035 Stereo Encoder / Multiplexer Kit
NJM2035 Stereo Encoder / Multiplexer kit connects to mono FM transmitter and converts it into HI-FI Stereo FM Transmitter. Features rock solid stereo MPX and PILOT clock based around 38KHz crystal. Stereo encoder is supplied 1.5 - 3 Volts and draws only 2mA of current. Built-in stereo pre-emphasis enhances and produces crystal clear audio output. NJM2035 chip is manufactured by NJR CORPORATION (JRC), a subsidiary of New Japan Radio, a company that is known as the world's best manufacturer of high end professional audio semiconductors.
Specifications
Audio Input: Stereo
Output: MPX (connects to transmitter audio input)
SNR: 67dB
Channel Separation: 40 dB
Power Supply: 1.5 - 3V
Operating Current: 2mA
Dimensions: 1" x 1.75" (28mm x 46mm)
Component List
1x NJM2035 IC
1x Stereo Encoder PCB
1x 38KHz Crystal
1x 33uF Capacitor
1x 10uF Capacitor
3x 100nF Capacitor
2x 1nF Capacitor
1x 100pF Capacitor
1x 10pF Capacitor
1x 82K Resistor
2x 47K Resistor
2x 27K Resistor
1x 10K Resistor
1x Schematic with instructions |
|
|
|
TDA7000 FM Receiver (Parts)
This simple one chip FM receiver / TV tuner will allow you to receive frequencies from 70 up to 120MHz. With this small receiver it is possible to pick up TV stations, entire 88 - 108MHz FM band, aircraft conversation and many other private transmissions. It is a perfect companion to any FM Transmitter especially if FM band in your area is very crowded. TDA7000 receiver offers very good sensitivity therefore it will even allow you to pickup weaker signals that cannot be heard on conventional FM receivers. A neat feature of presented TDA7000 FM receiver is a voltage controlled oscillator similar to TV tuners that are used in television sets. Frequency is tuned by varying the input voltage to the oscillator. The advantage of this type of oscillator is that you can use regular 100K potentiometer to precisely tune to a given broadcast. Tuning can be performed much quicker and precisely than by using a trimmer (variable capacitor). Trimmers will also shift the frequency as you touch them where potentiometer will not. Trimmer also needs to be placed on receiver's PCB to minimize the stray capacitance where potentiometer can be conveniently placed anywhere you want because it will not be affected by any external capacitance.
Click here to view TDA7000 FM receiver schematic & description
This is a list of included parts that are needed to build TDA7000 FM Receiver.
Component List:
1x TDA7000
1x 3.5T Variable Coil
1x MV2105 - Varicap Diode
1x 100K Potentiometer
1x 100K Resistor
1x 22K Resistor
3x 100nF Capacitor
1x 22nF Capacitor
1x 10nF Capacitor
2x 3.3nF Capacitor
1x 2.2nF Capacitor
1x 1nF Capacitor
2x 330pF Capacitor
2x 220pF Capacitor
2x 180pF Capacitor
1x 150pF Capacitor |
|
|
|
AM/FM Radio Receiver with Speaker and Antenna
Small AM/FM Radio Receiver with slim speaker and telescopic antenna. The board features single chip TDA7088 FM receiver, TO92 AM receiver and 1W amplifier. Receiver offers excellent sensitivity and impressive loudness from included speaker. Just connect red (+) and black (-) leads to 3V voltage supply (two AA/AAA battery cells), extend telescopic antenna and you are ready to listen to your favorite AM/FM radio stations.
Specifications:
FM Frequency Range: 87 - 108 MHz
AM Frequency Range: 525 - 1607 KHz
Voltage Supply: 3V (Two AA/AAA batteries)
Onboard single chip TDA7088 FM receiver, TO92 AM receiver and 1W amplifier
Includes PCB Receiver, Speaker, Antenna and Earphone jack
PCB Dimensions: 1.5" x 3" (4.5cm x 8cm) |
|
|
|
Accurate LC Meter Kit with Green Backlight LCD
Build your own high quality Accurate LC Meter and start making custom made coils and inductors. Accurate LC Meter allows to measure incredibly small inductance making it perfect tool for making all types of RF coils and inductors. LC Meter can measure inductance starting from only 10nH - 1000nH, 1uH - 1000uH, 1mH - 100mH and capacitance from 0.1pF up to 900nF. The circuit includes and auto ranging feature and a reset switch.
This kit comes with all the components including programmed PIC16F628A microcontroller chip, detachable LCD display with green backlight, switches and all the other components that are needed to build high quality LC Meter. Kit includes high quality PCB with green solder mask, pre-soldered tracks for easier soldering and LC Meter instruction manual. Thanks to the use of LCD male/female header connectors LCD display can be detached from the main PCB board at any time even after the kit has been assembled. All components are through-hole and are easy to solder.
View LC Meter Schematic and Detailed Description
Specifications:
Voltage Supply: 6 - 16V
Current Consumption: 10mA
Dimensions: 80 mm x 36 mm x 23 mm (W x L x H)
Measures following inductance: 10nH - 1000nH, 0.1uH - 1000uH, 0.1mH - 100mH
Measures following capacitance: 0.1pF - 1000pF, 0.1nF - 900nF
Component List:
1x 16 x 2 LCD Display with Yellow-Green Backlight
1x LC Meter PCB
1x PIC16F628A Programmed Microcontroller IC
1x LM311 IC
1x 18 DIP IC Socket
1x 8 DIP IC Socket
1x LM7805 5V Regulator
1x 10K Potentiometer
1x 82uH Inductor
1x 4 MHz Crystal
1x 5V Reed Relay
1x L/C Pushbutton Switch with Black Cap
1x Tactile momentary reset switch with Black Cap
3x 10uF Capacitor
1x 100nF Capacitor
2x 1000pF Capacitor
2x 10pF Capacitor
1x 16-PIN LCD Female Header
1x 16-PIN LCD Male Header
1x 2-PIN Header
2x 1-PIN Header
3x 100K Resistor
1x 47K Resistor
2x 6.8K Resistor
1x 1K Resistor
1x 100 Resistor
1x 10 Resistor |
|
|
|
4-Channel 433MHz Wireless RF Remote Control - 200m (Transmitter + Receiver)
4 Channel RF Remote Transmitter and Receiver allows to remotely control four appliances. RF Remote Control provides 4 momentary outputs that can be wired to relays and control home appliances, lights, motors, light dimmers, robotic devices, RC cars, computer, etc. RF transmitter provides up to 100m range. Selection of custom address codes (by soldering pins) allows to operate more than one remote control system in the same area or to control one receiver with multiple transmitters. If required momentary outputs can be converted to toggle with low cost digital 4013 IC. 12V (27A) alkaline battery is included.
Features:
4 Momentary Outputs
200m Transmission Range
Small Size
Rock-solid oscillator provides reliable operation
Valid transmission LED status through VT connection
High noise immunity
Terminal pins provide simple connection to power supply and four devices
Selection of custom address codes (by soldering pins) allows to operate more than one unit in the same area
RF Transmitter Specifications:
Voltage Supply: 12V (27A Alkaline Battery)
Transmission Frequency: 433MHz
Transmission Range: 200m
Dimensions: 58 mm x 26 mm x 13 mm
RF Receiver Specifications:
Voltage Supply: 5V
Transmission Frequency: 433 MHz
Output Mode: Momentary
Power Consumption: 5 mA
Receiving Sensitivity: -101 dbm
Dimensions: 36 mm x 25 mm x 8 mm |
|
|
|
4-Channel 433MHz Wireless RF Receiver
This is an assembled 4 Channel RF Remote Receiver (without RF Remote Transmitter). RF Remote Control provides 4 momentary outputs that could be used to control your favorite devices such as amplifier's volume control, selection of audio sources, wireless light control, light dimmers, robotic devices, motors, RC cars, computer, home appliances, and many other cool gadgets. If required momentary outputs can be easily converted to toggle with 4013 digital low cost IC.
Features:
4 Momentary Outputs
Small Size
Rock-solid oscillator provides reliable operation
Valid transmission LED status through VT connection
High noise immunity
Terminal pins provide simple connection to power supply and four devices
Selection of custom address codes (by soldering pins) allows to operate more than one unit in the same area
RF Receiver Specifications:
Voltage Supply: 5V
Transmission Frequency: 433 MHz
Output Mode: Momentary
Power Consumption: 5 mA
Receiving Sensitivity: -101 dbm
Dimensions: 36 mm x 25 mm x 8 mm |
|
|
|
Dual Channel Voltmeter Kit
PIC voltmeter measures 0-70V voltage providing excellent reading accuracy and resolution. It has two input channels for measuring two voltage sources at the same time. PIC voltmeter kit uses PIC16F876A microcontroller with built-in ADC (Analog to Digital Converter) and 16 x 2 backlighted LCD display.
Volt meter kit comes with all components required to build high quality Dual Channel 70V PIC Voltmeter including premium quality PCB. Voltmeter can also measure AC voltage if rectifier diode is added to voltage input. This meter can both measure and be supplied by the same power source.
Dual Channel 70V PIC Voltmeter Schematic
Component List
1x 16 x 2 LCD Display with Green Backlight
1x PIC16F876A - Programmed microcontroller
1x High Quality PCB with red solder mask and plated through holes
1x 28-DIP IC Socket
1x 4MHz Resonator
1x 16 x 1 Gold Plated Male Header
1x 16 x 1 Gold Plated Female Header
1x 4 x 1 Gold Plated Header
1x LM7805 5V Voltage Regulator
1x 10K Trimmer Potentiometer
2x 100K 1% Metal Film Resistor
2x 6.8K 1% Metal Film Resistor
1x 10 1% Metal Film Resistor
1x 100nF Ceramic Capacitor
1x Manual with Schematic
|
|
|
|
4-Channel Remote Control System with Four Relays
Having the ability to control various appliances inside or outside of your house wirelessly is a huge convenience, and can make your life much easier and fun. RF remote control provides long range of up to 200m and can find many uses for controlling different devices around the house.
4 button RF remote is used to turn ON / OFF 4 different devices independently. 10A Relay outputs can switch appliances that use 110V / 220V mains voltage. 4-Channel Receiver board comes with toggle mode that allows to control each channel independently. Latch and momentary modes are also available per special order.
What's Included:
4-Channel RF Control Board (assembled)
4-Channel RF Remote Control with 12V Alkaline Battery
Specifications:
Transmission Distance: 200m
Transmission Frequency: 433MHz
Output Control Mode: Independent ON / OFF
Receiver Control Board Voltage Supply: 12V
Receiver Control Board Dimensions: 82mm x 52mm x 18mm
Remote Control Voltage Supply: 12V Alkaline 23A Battery (included)
Remote Control Dimensions: 58 mm x 26 mm x 13 mm (when antenna is not extended) |
|
|
|
Humidity Temperature Meter (Hygrometer)
Hygrometer thermometer simultaneously monitors both humidity and temperature on large LCD display which can be read from across the room. For labs, chemical storage areas, clean rooms, stock rooms, warehouses, factories, greenhouses, and outdoors. Monitor humidity and temperature in desiccators, incubators, refrigerators, and fume hoods. Comes with AG13/LR44 battery.
Specifications:
Temperature range: -10 C to 50 C (14 F to 122 F)
Humidity range: 20% RH to 99% RH
Temperature resolution: 1 C
Humidity resolution: 1% RH
Size: 57mm (L) x 32mm (W) x 11.5mm (H)
Battery: AG13/LR44 (included) |
|
|
|
PIR Motion Sensor Detector
PIR motion sensor allows to detect human's presence/motion. Great for security lights, security systems, toys, etc. PIR sensor offers adjustable sensitivity (1-7 meters / 3-20 feet), built-in timer adjustable from 2 - 200 seconds, wide 4V - 20 V voltage supply, ultra-low power consumption and small size. When person enters in PIR sensor work range the output PIN goes high (3V). When person leaves the sensor's range the output remains high for 2-200 seconds (adjustable) and turns off (0V).
Specifications:
Input Voltage: 4V - 20 V
Output PIN Voltage: 3V when ON, 0V when OFF
Micropower: quiescent current < 50 uA
ON Delay Timer: 2 - 200 seconds (adjustable)
Trigger mode: L - unrepeatable trigger / H - Repeatable Trigger (default)
Detector range: 1-7 meters / 3-20 feet (adjustable)
Detector angle: 140 Degrees
Dimensions: 24 x 32 x 28 mm (0.945 x 1.26 x 1.1 inch)
Working temperature: - 20˚C ~ + 60˚C
 |
|
|
|
BH1415 Stereo Encoder (parts, no PCB)
This is the latest MPX BH1415 Stereo Encoder that includes a lot of great features in one small package. The heart of Stereo Encoder is a new BH1415 chip from RHOM that includes components that were previously only available in expensive broadcast quality stereo encoders. Connect this stereo encoder to any mono FM transmitter to convert it into Hi-Fi stereo FM transmitter.
Circuit features built-in; crystal oscillator based stereo audio encoding, pre-emphasis for reducing transmission noise, limiter so that the music can be transmitted at the same audio level and 15KHz brickwall low pass filter that blocks any audio signals above 15KHz to prevent any RF interference.
For limited time we include SOIC 28 to DIL adapter free of charge.
Features
================
- Crystal based stereo encoder
- 15KHz brickwall filter
- Audio Limiter
- Pre-emphasis
- Excellent channel separation
Included Parts
================
1x BH1415 - Stereo PLL Transmitter IC
1x 7.6 MHz Crystal
1x 78L05 Voltage Regulator
1x 10K Resistor
3x 10uF Capacitor
2x 1uF Capacitor
2x 2.2nF Capacitor
1x 1nF Capacitor
2x 150pF Capacitor
2x 27pF Capacitor |
|
|
|
18W TDA2030A Hi-Fi Stereo Audio Amplifier Kit
Stereo power amplifier based around two TDA2030 ICs. It has good input sensitivity, low distortion, good operating stability and full protection against overloads and output short-circuits.
18W TDA2030A Stereo Audio Amplifier Kit can be used as a booster amplifier for existing small systems or to drive a second pair of speakers besides the ones already connected to the system.
The board needs a dual power supply of ±18V and can be connected to 8 or 4 Ohm speakers. Heatsink not supplied with the kit.
Specifications
Supply Voltage: +/- 9-12V AC (+/- 12V DC)
Output Power: 2x 18W, 1x 36W
Current consumption: 3A maximum
Input impedance: 500K Ohms
Input sensitivity: 250 mV
Signal to noise ratio: 80 dB
Frequency response: 20 - 20,000 Hz ± 1 dB
Distortion: 0.5 % maximum
Load impedance: 4 - 8 ohm
Dimension: 90mm x 40mm x 25mm |
|
|
|
24-Bit 192KHz PCM1793 Audio DAC (assembled)
This is an assembled PCM1793 Audio DAC board. PCM1793 DAC is perfect for upgrading audio components such as CD Player, DVD Player, Blue Ray Player, Computer, and Satellite receiver and can be easily connected via Coaxial S/PDIF or Optical Cable. PCM1793 Audio DAC board features advanced Burr-Brown PCM1793 DAC chip, OPA2134 op-amp, and latest DIR9001 digital line receiver. PCB board is built with high quality components such as Nichicon Audio capacitors, WIMA capacitors, gold plated connectors, gold plated PCB tracks and metal film resistors. PCM1793 DAC provides detailed sound with good sound stage, deep base and crisp hights.
Specifications
- 24-Bit 192kHz Sampling DAC
- Dynamic Range: 113 dB THD: 0.001%
- 8x Oversampling Digital Filter
- Coaxial S/PDIF or Optical Input
- Analog RCA Audio Output (Left & Right)
- Power Supply: 12V / 1A (DC)
- PCB Dimension: 100 mm x 60 mm |
|
|
|
6-Channel 433MHz Wireless RF Remote Control - 500m (Transmitter + Receiver)
This is an assembled 6 Channel RF Remote Transmitter and Receiver with 500m transmission range. Is simple to connect and it will allow you to remotely control various electronic projects. RF Remote Control provides 6 momentary outputs that could be used to control your favorite devices such as amplifier's volume control, selection of audio sources, wireless light control, light dimmers, robotic devices, motors, RC cars, computer, home appliances, and many other cool gadgets.
This item is also available in toggle (ON/OFF) version. Please contact us for more information.
Features:
6 Momentary Outputs (TTL compatible)
500m Transmission Range
Small Size
Rock-solid oscillator provides reliable operation
Valid transmission LED status through VT connection
High noise immunity
Terminal pins provide simple connection to power supply and six devices
Selection of custom address codes (by soldering pins) allows to operate more than one unit in the same area
RF Transmitter Specifications:
Voltage Supply: 12V (27A Alkaline Battery)
Transmission Frequency: 433MHz
Transmission Range: 500m
Dimensions: 85mm - 37mm - 16mm
RF Receiver Specifications:
Voltage Supply: 5V
Transmission Frequency: 433 MHz
Max Transfer Rate: 4.8K
Output Mode: Momentary (TTL compatible)
Power Consumption: 5 mA
Receiving Sensitivity: -103 dbm
Dimensions: 41mm x 26mm x 7mm |
|
|
|
200m 4-Channel Remote Control Transmitter
This is an additional 4-Channel RF Remote Transmitter with 200m range for controlling 4-Channel 433MHz Wireless RF Receiver with multiple Remote Transmitters.
This product is compatible with 4-Channel 433MHz Wireless RF Receiver and 4-Channel Remote Control System with Four Relays.
Features:
4 Channels
200m Transmission Range
Small Size
Rock-solid oscillator provides reliable operation
Transmission LED status
High noise immunity
Selection of custom address codes (by soldering pins) allows to operate more than one transmitter or receiver in the same area
RF Transmitter Specifications:
Voltage Supply: 12V (Includes 27A Alkaline Battery)
Transmission Frequency: 433MHz
Transmission Range: 200m
Dimensions: 58 mm x 26 mm x 13 mm |
|
|
|
50W TDA7294 Hi-Fi Mono Gainclone Audio Amplifier (Parts)
This package comes with high-end audio parts to build 50W hi-fi quality class AB audio gainclone amplifier using a TDA7294 IC. Amplifier provides an impressive 50W RMS into 8 Ohm or 82W RMS into 4 Ohm with only 0.1% THD. TDA7294 amplifier comes with internal thermal protection.
Specifications
=======================================
Power Supply ±30V
Input Sensitivity: 1.3V (50W into 8 Ohm)
Input Impedance: 10K Ohm
Freq. Response: 16Hz – 100KHz
Slew Rate: 10V/uS
Output Impedance: 4 - 8 Ohm
Output Power: 50W into 8 Ohm (0.1%THD)
82W into 4 Ohm (0.1% THD)
S/N Ratio: 105dBa (1W/8 Ohm)
THD (40W into 8 Ohm): 0.002% (1kHz)
<0.04% (20Hz – 20kHz)
Component List
=======================================
1x TDA7294
2x 1500uF / 50V Panasonic FC Audio Capacitor
2x 22uF / 25V ELNA Silmic II Audio Capacitor
1x 4.7uF / 25V ELNA Silmic II Audio Capacitor
2x 100nF / 100V WIMA MKS2 Polyester Film Capacitor
1x 1nF / 100V WIMA MKS2 Polyester Film Capacitor
1x 22K Dale RN55 Audio Resistor
2x 10K Dale RN55 Audio Resistor
1x 680 Dale RN55 1% Audio Resistor
1x 150 Dale RN55 1% Audio Resistor
1x Manual with schematic
Heatsink and PCB are not included.
|
|
|
|
USB 2.0 to RS232 Serial Adapter
USB to RS232 Adapter allows you to use serial hardware with your USB equipped laptop or desktop computer. The USB to Serial adapter connects RS-232 serial devices to your USB-equipped Windows host computer. It provides a bridge connection with a standard DB 9-pin male serial port connector in one end and a standard Type-A USB plug connector on the other end. Simply attach your serial device into the DB 9-pin end of the adapter cable and plug the USB connector into your PC's USB port.
Description:
Chip: PL2303
USB specification 1.1 and 2.0 compliant
Supports remote wake up and power management
Windows 98/SE/ME/2000/XP supported
Supports RS232 serial interface (DB25 or DB9)
Supports over 1Mbps data transfer rate
Cable length: 3 feet / 1 Meter
Comes with Windows 98/SE/ME/2000/XP drivers on included CD
Great for all PIC/AVR microcontroller projects
Can provide 5V / 500mA power for your electronic projects |
|
|
|
Camera Stobe Light Board
Small strobe circuit board made by Kodak for disposable cameras. These are new units and ready for use. Just insert a 1.5V AA alkaline battery (not included) and hold down the on/off lever. When the ready light comes on release the on/off lever and short the trigger wires together and you will see a brilliant white flash of light! Complete with all parts but no case. Size about 3.6" long x 2.0" wide x 1.2" thick. |
|
|
|
3.5mm Shielded Stereo Audio Cable - Male to Male - 2 FT
2 Feet Black Plug Shielded Audio Cable. Connects the 3.5mm Jack from CD players, stereo speakers, PC/TV tuners, and other audio devices. Fully molded construction and shielded to prevent unwanted EMI/RFI interference. Can be cut in half and be used to connect transmitters to MP3, CD player, computer and other audio equipment. |
|
|
|
|
